STW Low Bed Scissor Lift 1000 KG STW/LBSL/1000KG

by STW

(65)

Add to Wishlist Add to Compare

Rs. 1,92,000

(Taxes and Transportation Extra)

LOW BED (‘U’ TYPE) HYDRAULIC ELECTRIC STATIC SCISSOR LIFTING TABLE LIFTING PLATFORM HU SERIES • ‘U’ SHAPED PLATFORM • ‘U’ SHAPED TABLE ARE SPECIALLY FOR HANDLING PALLETS, NO NEED FOR A PIT OR LOAD RAMPS • THEY ARE MANUFACTURED TO ALL EUROPEAN SAFETY STANDARDS INCLUDING EN1570:1990 • REMOTE POWER PACKWITH PEDESTAL AND CONTROLS ,PRETECTED TO IP54 • UPPER PLATFORM FITTED WITH SAFETY PERIMETER TO PREVENT DESCENT ON CONTACT WITH OBSTRUCTIONS • 24V CONTROL BOX WITH UP AND DOWN BUTTONS AND EMERGENCY STOP • EXTERNAL POWER PACK EQUIPPED WITH A RELIEF VALVE AGAINST OVERLOADING AND A COMPENSATED FLOW VALVE FOR CONTROLLING LOWERING SPEED • HOSE BURST SAFETY VALVE TO STOP THE LIFT TABLE LOWERING IN CASE OF HOSE BREAKAGE • REMOVABLE LIFTING EYES TO FACILITATE HANDLING AND INSTALLATION OF THE LIFT TABLE • MECHANICAL SAFETY CHOCKS FOR MAINTENANCE • OILESS BUSHINGS ON PIVOT POINTS • QUICK ASSEMBLY JOINT FOR OIL HOSE

Get Quote

Rent this instead

Product Specifications

Manufacturer	SPECTRUM TECH WORLD
Capacity	1000 KG
Model	STW/LBSL/1000KG

View More Specification

LOW BED (‘U’ TYPE) HYDRAULIC ELECTRIC STATIC SCISSOR LIFTING TABLE LIFTING PLATFORM

HU SERIES

‘U’ SHAPED PLATFORM
‘U’ SHAPED TABLE ARE SPECIALLY FOR HANDLING PALLETS, NO NEED FOR A PIT OR LOAD RAMPS
THEY ARE MANUFACTURED TO ALL EUROPEAN SAFETY STANDARDS INCLUDING EN1570:1990
REMOTE POWER PACKWITH PEDESTAL AND CONTROLS ,PRETECTED TO IP54
UPPER PLATFORM FITTED WITH SAFETY PERIMETER TO PREVENT DESCENT ON CONTACT WITH OBSTRUCTIONS
24V CONTROL BOX WITH UP AND DOWN BUTTONS AND EMERGENCY STOP
EXTERNAL POWER PACK EQUIPPED WITH A RELIEF VALVE AGAINST OVERLOADING AND A COMPENSATED FLOW VALVE FOR CONTROLLING LOWERING SPEED
HOSE BURST SAFETY VALVE TO STOP THE LIFT TABLE LOWERING IN CASE OF HOSE BREAKAGE
REMOVABLE LIFTING EYES TO FACILITATE HANDLING AND INSTALLATION OF THE LIFT TABLE
MECHANICAL SAFETY CHOCKS FOR MAINTENANCE
OILESS BUSHINGS ON PIVOT POINTS
QUICK ASSEMBLY JOINT FOR OIL HOSE

More Details

Specification

Type Of Product	LOW BED SCISSOR LIFT
Manufacturer	SPECTRUM TECH WORLD
Capacity	1000 KG
Operator Type	ELECTRIC
Model No	STWLBSL1000KG

More Specification

STW

SPECTRUM TECH WORLD (STW)

Similiar Category

Different Products

WhatsApp Image 2024-11-12 at 2.33.03 PM.jpeg

Stw Hydraulic Goods Lift Ss 304 Singal Mast 800 KG STW/GLSM/SS-304/800 KG

Rs. 6,50,000

Product Name	STW Low Bed Scissor Lift 1000 KG STW/LBSL/1000KG
Manufacturer	SPECTRUM TECH WORLD
Capacity	1000 KG
Operator Type	ELECTRIC
Model No	STWLBSL1000KG
Max Lift Height	860 MM
Platform Length	1450 MM
Platform Width	1140 MM
Hydraulic Cylinder No	2

STW Low Bed Scissor Lift 1000 KG STW/LBSL/1000KG

Rs. 1,92,000

(Taxes and Transportation Extra)
